Marchio: Vibro-MeterDescrizione: accelerometro piezoelettricoCONDIZIONE: nuovo di zeccaCertificato: lettera di garanzia del rapporto di test COOGaranzia: 1 annoInventario QTY: 30Termina di pagamento: t/tPorta di spedizione: ShenzhenCA202 144-202-000-203 Accelerometro piezoelettrico: sensore intrinsecamente sicuro con protezione di livello militare, progettato per il monitoraggio delle vibrazioni ad alta precisione in ambienti esplosivi ad alto rischio (Zona 0) e condizioni di lavoro dure di -55 ℃ ~ 260 ℃.
|
Manufacture |
VIBRO-METER |
|
Model Number |
CA202 |
|
Ordering Number |
144-202-000-203 |
|
Country Of Origin |
Switzerland |
|
HS CODE |
9031809090 |
|
Dimension |
10*10*8CM |
|
Packing Dimension |
15*15*10CM |
|
Weight |
0.5kg |
Professional Industrial Vibration Monitoring Solution
Made by Meggitt’s vibro-meter brand, designed for harsh industrial environments
Core Benefits
Excellent Sensitivity:
-100 pC/g high sensitivity, dynamic measurement range 0.01–500 g
-Wide frequency response range 0.5–6000 Hz (±5% accuracy)
Military-grade protection:
-Fully sealed austenitic stainless steel housing (IP68 equivalent)
-High temperature resistance: -55℃ to 260℃ continuous operation (sensor body)
-Corrosion resistance: 100% moisture/oil/salt spray proof
Intrinsically safe certification:
- Available in Ex ia (intrinsically safe) and Ex nA (non-sparking) versions
- Passed global explosion-proof certifications such as ATEX, IECEx, KGS, etc. (Zone 0/1/2)
Key design
Differential output structure:
-Symmetrical shear piezoelectric crystal design, internal shell insulation
-Lateral sensitivity ≤±2%, linearity ±1%
Integrated protection:
-Standard stainless steel armored cable (3m/6m/11m/20m optional)
-Laser sealing welding of cable and sensor to eliminate leakage risk
Ready to install:
-Standard M6 mounting hole (torque 15N·m)
-No additional insulation treatment required
11m/20m cable can be customized for special needs
